Aten KVM-Switch 8-fach VGA/PS2, Stackable

Több mint 100.000 termék azonnal raktárról<

Több mint 100.000 termék azonnal raktárról

Megbízható, elismert világmárkák

Megbízható, elismert világmárkák

30 év szakmai tapasztalat

30 év szakmai tapasztalat

Versenyképes árak

Versenyképes árak

Figyelem! A termékleírások automatizált fordítószoftver által jöttek létre.
Termékinformációk "Aten KVM-Switch 8-fach VGA/PS2, Stackable"

grau, 1HE, OSD Maus-/Tastatursimulation f. NT/Novell Auflösung VGA:2048x1536; DDC2B, Tischgerät/19"-fähig, Master View Pro,

Console: 2xPS/2 Buchse, 1xVGA HDB-15 Buchse

PC1-8: je( SPHD-15 Buchse)

Daisy-Chainports: IN, out,

8-Port PS/2 KVM Switch



ATEN's high performance KVM switch offers one of the most streamlined approaches to server-network management. With its advanced engineering and high density console connectors, a single unit occupies only 1U of rack space and can control up to 256 computers.





Patent NO. : TW 183765(Taiwan) ,CN ZL 02122202.9





Features





One PS/2 console controls 8 computers.

Daisy chain up to 31 additional units - Control up to 256 computers from a single console.

Firmware upgrades to all the chained KVM switches at the same time via the daisy chain cable.

Buzzer ON/OFF via hotkey and OSD.

Broadcast Mode: Operations simultaneously performed on all selected computers, software installation and upgrading, system wide shutdown....etc.

Auto-sensing of station's position on daisy chained installations - no need for manual DIP switch setting - front panel LED indicates station's position.

Computer selection via hotkeys and OSD.

Superior video quality- up to 2048 x 1536; DDC2B.

Rack mountable in 19" system rack.

Multiplatform support: Windows 2000/XP/Vista, Linux and FreeBSD.

For more information about KVMs which can connect to ACS1208A, see Compatible KVM Table.





Package Content





1x 8-Port PS/2 KVM Switch

2x PS/2 KVM Cable (1.8m)

1x Firmware Upgrade Cable

1x Power Adapter

1x Rack Mount Kit

1x User Manual





Diagram





+ View enlargement





Specification





Computer Connections Direct 8

Max via 256 (via Daisy Chain)

Port Selection Hotkeys, OSD

Connectors Console

Ports Keyboard 1 x 6-pin Mini-DIN Female (Purple)

Video 1 x HDB-15 Female (Blue)

Mouse 1 x Mini Din 6 Female (Green)

KVM Ports Keyboard/

Video/Mouse 8 x SPHD-15 Female (Yellow)

Chain Ports In 1 x DB-25 Female (Black)

Out 1 x DB-25 Male (Black)

Fi/W Upgrade 1 x RJ-11 Female (Black)

Power 1 x DC Jack (Black)

Switches Fi/W Upgrade 1 x Slide

Reset 1 x Semi-recessed Pushbutoon

LEDs On Line 8 (Orange)

Selected 8 (Green)

Station ID 2 x 7-segement (Orange)

Power 1 (Blue)

Emulation Keyboard/Mouse PS/2

VGA Resolution 2048x1536;DDC2B

Operating temperature 0~50°C

Storage temperature -20~60°C

Scan Interval 1-255 Seconds

Power Consumption DC9V, 7.5W

Environment Operating Temp. 0-50°C

Storage Temp. -20-60°C

Humidity 0-80% RH, Non-condensing

Physical Properties Housing Metal

Weight 2.73kg

Dimensions ( L x W x H ) 43.30 x 16.00 x 4.40 cm
